●ELECTRICAL CHARACTERISTICS

Part Number	6dB Bandwidth	Selectivity (±9KHz off)	Insertion loss (dB)max.	Input/Output Impedance (Ω)	Center Frequency (KHz)
LPP450D LPP459D	±10	±20KHz off 40(50)	4.0	1500	450±1 459±1
LPP450F LPP459F	±6.0	±12.5KHz off 40(50)	6.0	1500	450±1 459±1
LPP450G LPP459G	±4.5	±9KHz off 30(40)	6.0	2000	450±1 459±1
LPP450H LPP459H	±3.0	±9KHz off 40(50)	6.0	2000	450±1 459±1
